| GEX3370 |
Silencer RH |
1 |
|
 |
|
|
0 |
| HN2008 |
Plain Nut 5/16" UNF 1/2" AF 0.270"/0.260" Nom Thickness |
3 |
|
|
|
|
1 |
| WL208 |
Spring Washer ID 5/16" OD 0.58" |
3 |
|
|
|
|
1 |
| WP107 |
Plain Light Washer ID 1/8" OD 1/2" |
3 |
|
|
|
|
1 |
| 155435 |
Clip |
3 |
|
|
|
|
0 |
| HB822 |
Hex Head Bolt 5/16" UNF x 2 3/4" |
3 |
|
 |
|
|
1 |
| WP107 |
Plain Light Washer ID 1/8" OD 1/2" |
3 |
|
|
|
|
1 |
| GEX3371 |
Silencer LH |
1 |
□ See 218470 for Alternative
|
|
|
|
0 |
| 218470 |
Silencer LH |
1 |
□ See GEX3371 for Alternative
|
|
|
LH |
0 |
| WL208 |
Spring Washer ID 5/16" OD 0.58" |
4 |
|
|
|
|
1 |
| WP17 |
Plain Light Washer 5/16" ID x 1" OD |
4 |
|
|
|
|
1 |
| GEX7330 |
Washer Rubber |
4 |
|
|
|
|
0 |
| 150759 |
Link Plate |
2 |
|
|
|
|
0 |
| GEX7329 |
Grommet |
4 |
|
|
|
|
0 |
| 150535 |
Distance Piece |
2 |
|
|
|
|
0 |
| GEX7329 |
Grommet |
4 |
|
|
|
|
0 |
| 150759 |
Link Plate |
2 |
|
|
|
|
0 |
| GEX7330 |
Washer Rubber |
4 |
|
|
|
|
0 |
| WP17 |
Plain Light Washer 5/16" ID x 1" OD |
4 |
|
|
|
|
1 |
| HN2008 |
Plain Nut 5/16" UNF 1/2" AF 0.270"/0.260" Nom Thickness |
4 |
|
|
|
|
1 |
| WP17 |
Plain Light Washer 5/16" ID x 1" OD |
2 |
|
|
|
|
1 |
| 155435 |
Clip |
2 |
|
|
|
|
0 |
| WP17 |
Plain Light Washer 5/16" ID x 1" OD |
2 |
|
|
|
|
1 |
| HB830 |
Hex Head Bolt 5/16" UNF x 3 3/4" |
4 |
□ Easier to assemble if slightly longer bolts are used, i.e. 4"
|
 |
|
|
1 |
