| UKC8848 |
Valve Assembly |
1 |
□ In Parts Book Index as 156465
□ Missing from Parts Book Index. |
 |
|
|
0 |
| 144687 |
Core Plug |
1 |
□ Can be a point of Leakage into the V if the Car Has Been Run Without Anti Freeze. Fits to Underside of Inlet Manifold.
|
|
|
|
0 |
| 217594 |
Carb to Manifold Adaptor |
1 |
|
|
|
|
0 |
| 157181 |
Stud |
8 |
|
|
|
|
0 |
| DS1907 |
Spring Tension Dowel (Size Unknown) |
1 |
|
|
|
|
1 |
| HB874 |
Hex Head Bolt 5/16" UNC x 3" |
4 |
|
 |
|
|
1 |
| WP8 |
Plain Light Washer ID 5/16" OD 0.69" |
4 |
|
|
|
|
1 |
| 153068 |
Inlet Manifold Gasket - Rear |
2 |
|
|
|
|
0 |
| WP8 |
Plain Light Washer ID 5/16" OD 0.69" |
8 |
|
|
|
|
1 |
| HN2009 |
Hex Nut 3/8" UNF x 9/16" AF 0.330/0.320 Thk |
1 |
|
|
|
|
1 |
| WF509 |
Fibre Washer ID 3/8" OD 5/8" |
1 |
|
|
|
|
1 |
| HU858 |
Hex Head Setscrew 5/16" UNC x 1" |
8 |
|
|
|
|
1 |
| WF510 |
Fibre Washer ID 7/16" OD 11/16" |
1 |
|
|
|
|
1 |
| 159823 |
Connector Tube |
1 |
|
|
|
|
0 |
| 157911 |
Tube Connector |
1 |
|
|
|
|
0 |
| 309114 |
Inlet Manifold |
1 |
□ Up to LE10,000E
|
|
|
|
0 |
| 312506 |
Inlet Manifold |
1 |
□ From LE10,000E
|
|
|
|
0 |
| TD978 |
Stud - Carb Pedestal to Manifold (Size Unknown) |
1 |
|
|
|
|
1 |
| 153034 |
Adaptor 'O' Ring |
1 |
|
|
|
|
0 |
| 153063 |
Inlet Manifold Gasket - Front |
2 |
|
|
|
|
0 |
| 153198 |
Water Return Union Pipe |
1 |
|
|
|
|
0 |
| 158079 |
Adaptor |
1 |
|
|
|
|
0 |
Next Page: 02-31
